Signal Transformer
-
Telecom/Audio Transformer
❖ Introduction
• Provide line isolation, impedance matching and line balance
• Voice & Data Coupling transformers
• Frequency range: 300Hz to 10KHz
• Wet(with DC) / Dry(No DC) transformer circuits
❖ Advantage
• Low Profile SMD & Through Hole Packages
• Custom Design Available
• Designed to meet FCC Part 68
❖ Application
• High speed modem V.90 & V.92 application
• Telephone Coupling / Modem-Analog V.29, V.32 .V.34 & V.fast
• Telephone Coupling / FAX -
LAN Transformer
❖ Introduction
• 10/100/1000 Base ~ 10G base
• 16pin, 24pin, 48pin ~ till 96pin, SMD/DIP
• PoE, PoE+, PoE++ Transformer
❖ Advantage
• Compact size/ Thinner
• Short Lead Time
• Design Flexibility
• Competition Solution
• Vertical Integration
• Automation
❖ Application
• Switches/Router
• Servers
• Gateways
• Access Points
• Base Stations
• Automotive -
xDSL Transformer
❖ Introduction
• ADSL /2/2+ Transformers
• VDSL /2/2+ Transformers
• G. Fast Transformers
❖ Advantage
• Correspond to unique DSL chipset broadband transmission
requirements
• Customization Cheaper solution
• IEC60950-1 compatible
❖ Application
• ADSL, VDSL, HDSL
• Cable Modem in broadband transmission industry
• Access networks/Central Office(CO)
• Gateway/Customer Premise Equipment(CPE) -
PLC Transformer
❖ Introduction
• Power line/coupling/Power transformer
• Chipset design in reference
• Provide the package support (PLC coupling + Power transformer
+ CM Choke)
❖ Advantage
• Designed to meet appropriate safety standards
• Low Profile Package
• Custom Design Available
❖ Application
• Home plug / Power Line Coupling -
Chip Lan Transformer
❖ Introduction
A Chip LAN transformer is a discrete, center-tapped component wound
on a drum core and capped with a ferrite plate to emulate the result of
the close magnetic path of a toroid core
❖ Advantage
• Compliant With Ethernet 10/100/1000 Base-T
• Compliant With Ethernet 2.5/5G and 10G Base-T
• 100 % Automatic Production
• Improved Return Loss And Crosstalk Properties
• Super Small Size
• Operating Temperature: -40 °C ~ +105 °C
❖ Application
• Ethernet Connector Module Router G.Fast
