Heim / Produkte / Industrial Display / 2405-Y

Stretch Digital Display

2405-Y

24" Stretched LCD, 1000nits LED backlight, 1920 x 360, ultra-wide
  • Ultra-Wide Screen (16 : 3)
  • High Brightness
  • Sunlight Readable
  • LED Backlight
  • Low Power ConsumptionBL MTBF: 100,000 hours
Drucken
Anfrage Vergleich
Spezifikationen
Model name SSF2405-Y SSH2405-Y SSD2405-Y
Description 24” LCD, 1000nits LED backlight, 1920 x 360 ultra-wide aspect ratio 16:3
Size 24”
Display area (mm) 597.8(H) x 112.1(V)
Brightness 1000 cd/m²
Resolution 1920x360
Aspect ratio 16 : 3
Contrast ratio 850 : 1
Pixel pitch (mm) 0.3114(H) x 0.3114(V)
Pixel per inch (PPI) 81
Viewing angle 178°(H),178°(V)
Color saturation (NTSC) 81%
Display colors 16.7M
Response time (Typical) 30ms
Video interface LVDS VGA, DVI-D, HDMI
Input power DC12V
Power consumption 21W 27.5W
Dimensions (mm) 612.7x 132.1 x 12.8 617.8 x 137.2 x 45
Bezel size (U/B/L/R) 11/6/6/6 18.2/9.3/9.2/9.2
Weight (Net) 1.23 kg 4.6 kg
Mounting   VESA 75x75, 250x75
Operating temperature 0 ˚C ~ 50 ˚C
Storage temperature -20 ˚C ~ 60 ˚C
Product approval   CE, FCC
